#61 OFFLINE   mr ford

mr ford

    Team Shelby New Member

  • Members
  • Pip
  • 353 posts
  • Joined 21-April 07

Posted 22 December 2009 - 03:57 PM

deleted

Edited by mr ford, 04 January 2010 - 07:15 PM.

Dynatech Headers
Custom baffled Mac mufflers
FRPP Shifter
FRPP 3:73 Gears
Innovative Tuned
2.65 Pulley/Idler
Steeda CIA
FRPP Springs
Off Road -X
FRPP Valve covs
FRPP Diff Cov
I see a Kenny Bell in my future.....Never did see it.........
Sold and Mustangless

#62 OFFLINE   Grabber

Grabber

    TS Member #26

  • Moderator
  • 35,148 posts
  • Joined 21-July 06
  • Region:Pacific Northwest

Posted 24 December 2009 - 09:28 AM

Article 05-B-2009
Mustang GT500 Normal Operation
2007- 2009 Mustang GT500

A review of warranty claims and returned parts has found that some dealers are replacing the clutch assembly for normal operating characteristics of the GT500 clutch assembly.

The GT500 Owners Guide, page 8 and 9, describes the normal operating characteristics of the twin disc Cera-Metallic clutch. These are:

Clutch chatters/shudder when engaging the clutch.

Narrow or abrupt engagement points.

Hiss upon clutch engagement or disengagement.

Transmission gear roll over noise at idle.

Gear rattle noise at very low speeds when in 1st or 2nd gear.

Normal wear.

Performing repairs on vehicles determined to have normal operation could be considered over repair or misdiagnosis and may be subject to charge back.

Category: Powertrain / Manual Transmission

Do: Follow TSB 09-09-02 and the Shop Manual when addressing concerns with GT500 clutch and/or transmission shifting issues.

Don't: Do not replace the clutch disc if the customer concern matches the normal characteristics described in the Owners Guide.


GRABBER Posted ImagePosted Image
Posted Image 2007 GRABBER ORANGE GT500 Coupe ordered 10/13/06. Sub to plant 12/14/06. Scheduled 1/16/07. Bucked 1/17/07. Released From Plant 1/19/07. Plant Quality Hold 1/19/07. Off Plant Quality Hold 2/21/07. Shipped 2/22/07. Delivered 3/8/07. New 2008 2nd Gen. Tranny & Nickle Hub Clutch & Flywheel & Lube & CSC bearing 1/16/2008. New 2009 2nd Gen. Flywheel & another new Nickel Hub Clutch & Pilot Bearing 8/8/08. New 2010 Clutch and flywheel and slave cylinder & pilot bearing and clutch line 8/2/12
Posted ImagePosted ImagePosted Image

#63 OFFLINE   username1

username1

    Team Shelby New Member

  • Members
  • Pip
  • 80 posts
  • Joined 07-January 09
  • Interests:2007 grabber orange gt500

Posted 24 December 2009 - 10:38 AM

thumbs down to that news
2007 gt500 kb stage3, lower pulley, raven racing heat exchanger, bassani headers, catback, metco uca/lca panhard bar, frpp springs, nitto 555r's. 717.58 rwhp 610.18 tq

#64 OFFLINE   stillmy428

stillmy428

    Team Shelby New Member

  • Great Lakes Region
  • 78 posts
  • Joined 01-April 07
  • Region:Decline

Posted 01 January 2010 - 07:04 AM

Well my car has been in garage since Dec.1...Dealer has been real nice on the issue.Tech said tranny passed test but they are replacing clutch,flywheel,etc.The mechanic that is doing the work called when he got everything tore down.Flywheel, and clutch looked like they had 50,000 miles on them instead of 3,000.The dealer called just before christmas to let me know they haven't forgot about my car,but Brain the mechanic had lots of time left to use up.So the car sits on a rack all covered up in nice warm garage.Told him not hurry ....Spring will be here soon.So i hope all goes well with job,won't be able to drive it because of this lovely Ohio weather.
Visit My Website2007 Shelby GT500 Convertible
Alloy with Tungensten Strip
Posted Image
Ordered 3-26-07
Serail Numbered 3-29-07
Build 4-23-07
Dealer 4-25-07
Picked up 4-28-07

#2695 of 2276
#92 of 108 in Alloy

Added CDC Light bar
Lowered rear end
Shelby caps on engine
Lower control arms
sequential turn signals
signed plaque
Cobra center caps

#65 OFFLINE   Proctoman

Proctoman

    Team Shelby New Member

  • Members
  • Pip
  • 23 posts
  • Joined 18-April 08

Posted 14 January 2010 - 01:54 PM

I just wanted to let my fellow Shelby owners know that I just had the TSB completed at Galpin Ford in North Hills (Los Angeles) CA. I did not even purchase my car from there, and there was not one question asked even about about my mods. The took my car in and returned it in four days without a hitch. Way to go Galpin.
08 GT500 Coupe Vapor Silver/Black Stripes

Shorty antenna
Steeda LCAs
Steeda Adjustable UCA
FRPP shifter
JLT CAI
2.3L TVS
2.6 Upper
AUX Idler
Lund Tune
NGK TR6 plugs
3,73
C&R Dual HE
MAFia
Corsa Ultimate Touring Axel Backs
1-Piece Aluminum Driveshaft
Matching Mirror Covers & 3-D Carbon window/side Scoops
Shelby head/Arm rest cover.
Shelby Dash Plaque
Kenwood DNX8120, Jl Audio 1700 Watts, JL Audio 12 " Subs, K40 built in radar detector

#66 OFFLINE   Boss429

Boss429

    Team Shelby New Member

  • Members
  • Pip
  • 63 posts
  • Joined 21-August 06
  • Region:Great Lakes

Posted 19 January 2010 - 04:58 AM

Anyone from Wisconsin have this repair done? If so, what dealership did you go to and how was the experience?

Appreciate the help.
2007 Shelby GT500 - Performance White / Vista Blue Stripes

suspension
FRPP Handling Pack - Dampers (M-18000-C), Lowering Springs (M-5300-L), Anti-roll bar kit (M-5490-B), Strut Tower Brace (M-20201-C)
Steeda Adjustable Panhard Bar (555-2551)
Maximum Motorsports Adjustable C&C Plates (MM5CC-1)

powertrain/exhaust
FRPP CAI and Pro-Cal Tune (M-9603-SVT07)
FRPP Short Throw Shifter (M-7210-B)
FRPP White Shifter Knob w/ Stainless Steel Handle (M-7213-K)
FRPP FR500S GT500 KR Muffler Kit (M-5230-S)

interior
GT500 Carroll Shelby Signed Dash Plaque
GT500 Trunk and Floor Mats

other
Drake Muscle Cars Sequential Tail Light Harness (11044)

Shelby GT500 Billet and Carbon Fiber Engine Cap Set (Z30-S7M-6766-C)
SilverHorseRacing Flush-Mount Quarter Window Louvers (S197-300)
Redline Tuning QuickLift Elite Hood Struts (21-11023,4-0X Version 2)
Bangastang Radiator Cover (RCGT500)


Others In The Stable
1989 LX 5.0 Coupe - Grey (ALL STOCK)
2013 Boss 302 - School Bus Yellow - Build Date 10/15/2012. Boss # 2607

#67 OFFLINE   Boss429

Boss429

    Team Shelby New Member

  • Members
  • Pip
  • 63 posts
  • Joined 21-August 06
  • Region:Great Lakes

Posted 27 January 2010 - 04:09 AM

Anyone from Wisconsin have this repair done? If so, what dealership did you go to and how was the experience?

Appreciate the help.



Seriously, no one from WI? Cool, I have the only 07-09 GT500 in WI. Nice!
2007 Shelby GT500 - Performance White / Vista Blue Stripes

suspension
FRPP Handling Pack - Dampers (M-18000-C), Lowering Springs (M-5300-L), Anti-roll bar kit (M-5490-B), Strut Tower Brace (M-20201-C)
Steeda Adjustable Panhard Bar (555-2551)
Maximum Motorsports Adjustable C&C Plates (MM5CC-1)

powertrain/exhaust
FRPP CAI and Pro-Cal Tune (M-9603-SVT07)
FRPP Short Throw Shifter (M-7210-B)
FRPP White Shifter Knob w/ Stainless Steel Handle (M-7213-K)
FRPP FR500S GT500 KR Muffler Kit (M-5230-S)

interior
GT500 Carroll Shelby Signed Dash Plaque
GT500 Trunk and Floor Mats

other
Drake Muscle Cars Sequential Tail Light Harness (11044)

Shelby GT500 Billet and Carbon Fiber Engine Cap Set (Z30-S7M-6766-C)
SilverHorseRacing Flush-Mount Quarter Window Louvers (S197-300)
Redline Tuning QuickLift Elite Hood Struts (21-11023,4-0X Version 2)
Bangastang Radiator Cover (RCGT500)


Others In The Stable
1989 LX 5.0 Coupe - Grey (ALL STOCK)
2013 Boss 302 - School Bus Yellow - Build Date 10/15/2012. Boss # 2607

#68 OFFLINE   bcinu

bcinu

    Team Shelby New Member

  • Southern Plains Region
  • 18 posts
  • Joined 18-January 10
  • Region:Decline
  • Interests:need for speed whether 4 wheels or two

Posted 27 January 2010 - 03:02 PM

Seriously, no one from WI? Cool, I have the only 07-09 GT500 in WI. Nice!



I took my 07 in to Mac Haik Ford here in Houston and they got the TSB done in 2 days and I was out enjoying my convertible in 70 degree temp and blue skies!
This car happens to be one that was traded in because a couple of dealers in the area wouldn't do the TSB. So lucky me :) had 2518 miles on it.

Attached Files


Edited by bcinu, 28 January 2010 - 04:07 PM.


#69 OFFLINE   Grabber

Grabber

    TS Member #26

  • Moderator
  • 35,148 posts
  • Joined 21-July 06
  • Region:Pacific Northwest

Posted 15 February 2010 - 09:35 PM

TSB
09-19-11

SHELBY GT500 - CLUTCH DRAG - BUILT BEFORE 9/1/2008

This article supersedes TSB 9-9-2 to update the Service Procedure and Part List

ISSUE:
Some 2007-2009 Mustang Shelby GT500 vehicles built before 9/1/2008 may exhibit the following clutch/transmission symptoms: hard to disengage or engage 1st and reverse, hard to shift any gear, vehicle creeps with transmission in gear and clutch pedal fully depressed without brake pedal application. These symptoms may be caused by the clutch not disengaging fully when the clutch pedal is fully depressed. This may be due to flywheel distortion caused by excessive heat build-up during unique traffic conditions (example: severe stop/go urban driving, excessive clutch slipping). The clutch system is designed for performance driving conditions.

ACTION:
Follow the Service Procedure steps to correct the condition.
SERVICE PROCEDURE
Located at the end of the procedure are Figures 1, 2 and 3 which show the typical appearance of a flywheel and clutch that has been damaged due to overheating of the clutch. Figures 4, 5 and 6 show the typical appearance of a good flywheel and clutch.
This procedure does not apply to or correct the normal characteristics of the twin-disc cera-metallic clutch used in the Shelby GT500 vehicle or normal wear. The twin disc cera-metallic clutch incorporates racing technology to combine a low inertia assembly with a very durable friction material with high torque capability. Depending on your driving technique, the smoothness of how the clutch reacts to clutch engagements may be different from other vehicles that use a single disc clutch system. Also refer to pages 8 and 9 of the GT500 Owner Guide Supplement for additional information.
Normal Operating Characteristics Of The Twin Disc Cera-metallic Clutch
Clutch chatter/shudder when engaging the clutch.
Narrow or abrupt engagement point.
Hiss upon clutch engagement or disengagement.
Transmission gear rollover noise at idle.
Gear rattle noise at very low speeds when in 1st or 2nd gear.
Normal wear.


Transmission Synchronizer Diagnosis Procedure

The following procedure is to be used to determine if the synchronizer assemblies in the transmission may have been damaged by attempting to operate the vehicle with a dragging clutch.
1. Set parking brake.
2. Transmission in neutral.
3. Start engine and allow it to idle.
4. Clutch engaged - pedal fully released.
5. Attempt to shift transmission into first gear by firmly pushing shift lever approximately 5-10 lbf (22-45 N) force for 2-3 seconds.
6. If the synchronizers are okay, the transmission will not make any clash or grinding noise. You will not be able to move the gearshift lever into the selected gear (the synchronizer will block out gear engagement) and the engine RPM will decrease slightly.
7. Repeat the synchronizer test (Step 5 and 6) on all of the other forward gears.
a. If the transmission passes the synchronizer test, the transmission will not require additional service; proceed with clutch/flywheel replacement only. Refer to Clutch Replacement procedure.
b. If clash/grinding noise is found when performing the synchronizer diagnostic, the transmission will need to be repaired along with the replacement of the clutch. Refer to Transmission Repair procedure.
Clutch Replacement
1. Remove the transmission per Workshop Manual (WSM), Section 308-03C.
2. Remove and replace flywheel per WSM, Section 303-01C. Discard old bolts and use bolts provided in flywheel kit.
3. Install new pilot bearing per WSM, Section 308-01.
4. Install new clutch disc and plate assembly per WSM, Section 308-01 (vehicles with solid design flywheel). Discard old bolts and use bolts provided in clutch kit. Tighten bolts to 89 lb-in (10 N-m) in a star pattern. Tighten an additional 90 degrees in a star pattern.
5. Apply a small amount of Motorcraft® PTFE Lubricant to the clutch hub splines per WSM, Section 308-01.
6. Install the transmission per WSM, Section 308-03C.
Transmission Repair
1. Remove, drain, disassemble and clean the transmission per WSM, Section 308-03C.
2. Remove and replace input shaft and all synchronizer assemblies per WSM, Section 308-03C.
3. Assemble the transmission per WSM, Section 308-03C.
4. Install the transmission per WSM, Section 308-03C

PART NUMBER PART NAME
7R3Z-6375-B Flywheel Kit (Includes Bolts)
7R3Z-7L596-A Clutch Kit (Includes Bolts)
7R3Z-7C391-B Transmission Kit
XG-8 Motorcraft® PTFE Lubricant
XT-5-QM Motorcraft® MERCON® V Automatic Transmission Fluid
PM-1-C Motorcraft® High Performance DOT 3 Motor Vehicle Brake Fluid
XG-1-C Motorcraft® Premium Long-Life Grease
TA-30 Motorcraft® Silicone Gasket and Sealant
TA-25 Motorcraft® Threadlock and Sealer
F6ZZ-7600-A Pilot Bearing
1R3Z-7052-AA Transmission Input Shaft Oil Seal

WARRANTY STATUS:
Eligible Under Provisions Of New Vehicle Limited Warranty Coverage
IMPORTANT: Warranty coverage limits/policies are not altered by a TSB. Warranty coverage limits are determined by the identified causal part.
OPERATION DESCRIPTION TIME
091911A 2007-2009 Mustang GT500: Replace The Clutch Disc And Plate Assembly; Pilot Bearing And Flywheel. Includes Time To Remove And Install Transmission, Perform The Synchronizer Diagnosis (Do Not Use With Any Other Labor Operations) 3.9 Hrs.
091911B 2007-2009 Mustang GT500: Replace The Input Shaft; Synchronizer Assemblies, Clutch Disc And Plate Assembly; Pilot Bearing And Flywheel. Includes Time To Remove And Install Transmission, Perform The Synchronizer Diagnosis (Do Not Use With Any Other Labor Operations) 7.4 Hrs.

DEALER CODING
BASIC PART NO. CONDITION CODE
6375 69


NOTE: The information in Technical Service Bulletins is intended for use by trained, professional technicians with the knowledge, tools, and equipment to do the job properly and safely. It informs these technicians of conditions that may occur on some vehicles, or provides information that could assist in proper vehicle service. The procedures should not be performed by "do-it-yourselfers". Do not assume that a condition described affects your car or truck. Contact a Ford, Lincoln, or Mercury dealership to determine whether the Bulletin applies to your vehicle. Warranty Policy and Extended Service Plan documentation determine Warranty and/or Extended Service Plan coverage unless stated otherwise in the TSB article. The information in this Technical Service Bulletin (TSB) was current at the time of printing. Ford Motor Company reserves the right to supercede this information with updates. The most recent information is available through Ford Motor Company's on-line technical resources.
Copyright © 2009 Ford Motor Company


This TSB is now out of date and has been replaced with TSB 10-3-8
http://www.teamshelb...__fromsearch__1
GRABBER Posted ImagePosted Image
Posted Image 2007 GRABBER ORANGE GT500 Coupe ordered 10/13/06. Sub to plant 12/14/06. Scheduled 1/16/07. Bucked 1/17/07. Released From Plant 1/19/07. Plant Quality Hold 1/19/07. Off Plant Quality Hold 2/21/07. Shipped 2/22/07. Delivered 3/8/07. New 2008 2nd Gen. Tranny & Nickle Hub Clutch & Flywheel & Lube & CSC bearing 1/16/2008. New 2009 2nd Gen. Flywheel & another new Nickel Hub Clutch & Pilot Bearing 8/8/08. New 2010 Clutch and flywheel and slave cylinder & pilot bearing and clutch line 8/2/12
Posted ImagePosted ImagePosted Image

#70 OFFLINE   chuckstang

chuckstang

    Team Shelby Member

  • Members
  • PipPip
  • 3,445 posts
  • Joined 26-March 06

Posted 17 February 2010 - 07:11 PM

So when should we be expecting the 5th revision?

:jackinbox: :hysterical: :slapfight:
Posted Image

Ford Shelby GT500- Modified

#71 OFFLINE   cobrafan

cobrafan

    Team Shelby Member

  • Southern Plains Region
  • 1,773 posts
  • Joined 05-March 07
  • Region:Decline
  • Interests:Photography, Cycling, Backpacking

Posted 28 February 2010 - 08:54 PM

Grabber,

This is a little scary. I had the tranny replaced when I went in for the TSB in september 2008. Am I still in danger? This was the lastest and greatest at the time.

#72 OFFLINE   Grabber

Grabber

    TS Member #26

  • Moderator
  • 35,148 posts
  • Joined 21-July 06
  • Region:Pacific Northwest

Posted 01 March 2010 - 05:41 PM

Grabber,

This is a little scary. I had the tranny replaced when I went in for the TSB in september 2008. Am I still in danger? This was the lastest and greatest at the time.


Your fine. No worry.

The only thing you don't have is a new CSC and since yours is running good....it's OK.

Enjoy your car.
GRABBER Posted ImagePosted Image
Posted Image 2007 GRABBER ORANGE GT500 Coupe ordered 10/13/06. Sub to plant 12/14/06. Scheduled 1/16/07. Bucked 1/17/07. Released From Plant 1/19/07. Plant Quality Hold 1/19/07. Off Plant Quality Hold 2/21/07. Shipped 2/22/07. Delivered 3/8/07. New 2008 2nd Gen. Tranny & Nickle Hub Clutch & Flywheel & Lube & CSC bearing 1/16/2008. New 2009 2nd Gen. Flywheel & another new Nickel Hub Clutch & Pilot Bearing 8/8/08. New 2010 Clutch and flywheel and slave cylinder & pilot bearing and clutch line 8/2/12
Posted ImagePosted ImagePosted Image

#73 OFFLINE   pmustang

pmustang

    Team Shelby New Member

  • Members
  • Pip
  • 238 posts
  • Joined 06-April 10

Posted 08 April 2010 - 03:59 AM

Hello Folks, New poster here, New owner as well. I live in the UK (thus the car is not under ford warrantee so any work is to be paid for by myself or the seller) and have just bought a 2007 Shelby GT500. with sub 5k miles. The day after purchasing the car, owner still had it in his possession, the clutch went out. Reported by owner as a slippage in 5th and 6th gears with the garage (mustang specialist) feeling it is a clutch center plate (or pressure plate?) failure. He did not feel it was the flywheel as there is no judder at all. After speaking with several folks including one of the board members here I have ordered a flywheel as well. Figured it was insurance. The clutch and flywheel are Spec items and hopefully they are well thought of. It has been recommended to me by several threads, TSBs and a board member to change out the pump as well. Can anyone explain why this may be needed? The seller is paying for the R&R of the clutch and for the part itself. As I have chosed to do the flywheel I am paying for this. I don't want to change a pump with sub 5k miles on it unless it is needed. Supposedly it is quite involved to change out the pump? is that corrrect?

I am not going to dig into the trans as that has been reported to me by the shop doing the work (and by my test drive) to be working perfectly.

I appreciate any advice given.

Regards: Peter

#74 OFFLINE   DDT

DDT

    Dave

  • Members
  • PipPipPip
  • 5,936 posts
  • Joined 23-August 07
  • Interests:"Don't blame me"......."What did I do"???????

Posted 08 April 2010 - 06:57 AM

So when should we be expecting the 5th revision?

:jackinbox: :hysterical: :slapfight:


When a :censored: Load of 2010 Clutches start failing????????? :hysterical:

#75 OFFLINE   Grabber

Grabber

    TS Member #26

  • Moderator
  • 35,148 posts
  • Joined 21-July 06
  • Region:Pacific Northwest

Posted 08 April 2010 - 07:01 PM

Hello Folks, New poster here, New owner as well. I live in the UK (thus the car is not under ford warrantee so any work is to be paid for by myself or the seller) and have just bought a 2007 Shelby GT500. with sub 5k miles. The day after purchasing the car, owner still had it in his possession, the clutch went out. Reported by owner as a slippage in 5th and 6th gears with the garage (mustang specialist) feeling it is a clutch center plate (or pressure plate?) failure. He did not feel it was the flywheel as there is no judder at all. After speaking with several folks including one of the board members here I have ordered a flywheel as well. Figured it was insurance. The clutch and flywheel are Spec items and hopefully they are well thought of. It has been recommended to me by several threads, TSBs and a board member to change out the pump as well. Can anyone explain why this may be needed? The seller is paying for the R&R of the clutch and for the part itself. As I have chosed to do the flywheel I am paying for this. I don't want to change a pump with sub 5k miles on it unless it is needed. Supposedly it is quite involved to change out the pump? is that corrrect?

I am not going to dig into the trans as that has been reported to me by the shop doing the work (and by my test drive) to be working perfectly.

I appreciate any advice given.

Regards: Peter


Peter,

Change out the CSC. It only takes a few minutes and is very inexpensive.

Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
GRABBER Posted ImagePosted Image
Posted Image 2007 GRABBER ORANGE GT500 Coupe ordered 10/13/06. Sub to plant 12/14/06. Scheduled 1/16/07. Bucked 1/17/07. Released From Plant 1/19/07. Plant Quality Hold 1/19/07. Off Plant Quality Hold 2/21/07. Shipped 2/22/07. Delivered 3/8/07. New 2008 2nd Gen. Tranny & Nickle Hub Clutch & Flywheel & Lube & CSC bearing 1/16/2008. New 2009 2nd Gen. Flywheel & another new Nickel Hub Clutch & Pilot Bearing 8/8/08. New 2010 Clutch and flywheel and slave cylinder & pilot bearing and clutch line 8/2/12
Posted ImagePosted ImagePosted Image

#76 OFFLINE   pmustang

pmustang

    Team Shelby New Member

  • Members
  • Pip
  • 238 posts
  • Joined 06-April 10

Posted 08 April 2010 - 09:23 PM

Do you have a ballpark on the price ot that item in the USA? I am paying some steep prices for bits over here in the UK, I don't want to get too abused on this bit. Can't thank you enough for the photo, certainly appears to be much easier than I was thinking.

That is obviously sitting behind the flywheel and clutch assembly on the transmission?

Just a question, Why would you replace that item when doing a flywhell and clutch, Or is it obviously because its accessible and thus the time to do it?

Cheers. peter

#77 OFFLINE   Grabber

Grabber

    TS Member #26

  • Moderator
  • 35,148 posts
  • Joined 21-July 06
  • Region:Pacific Northwest

Posted 09 April 2010 - 06:12 PM

Do you have a ballpark on the price ot that item in the USA? I am paying some steep prices for bits over here in the UK, I don't want to get too abused on this bit. Can't thank you enough for the photo, certainly appears to be much easier than I was thinking.

That is obviously sitting behind the flywheel and clutch assembly on the transmission?

Just a question, Why would you replace that item when doing a flywhell and clutch, Or is it obviously because its accessible and thus the time to do it?

Cheers. peter


The CSC is under $100 here in the states. Yes it is on the front of the tranny and behind the flywheel and clutch. Here's a better pic of it. Also don't forget to use the teflon lube on the splines of the input shaft after you clean the shaft. Folks are replacing the CSC because it is so cheap and some have had problems. This part is what we used to call the throw out bearing. It makes the clutch work.

Posted Image
Posted Image
Posted Image

Edited by Grabber, 09 April 2010 - 06:13 PM.

GRABBER Posted ImagePosted Image
Posted Image 2007 GRABBER ORANGE GT500 Coupe ordered 10/13/06. Sub to plant 12/14/06. Scheduled 1/16/07. Bucked 1/17/07. Released From Plant 1/19/07. Plant Quality Hold 1/19/07. Off Plant Quality Hold 2/21/07. Shipped 2/22/07. Delivered 3/8/07. New 2008 2nd Gen. Tranny & Nickle Hub Clutch & Flywheel & Lube & CSC bearing 1/16/2008. New 2009 2nd Gen. Flywheel & another new Nickel Hub Clutch & Pilot Bearing 8/8/08. New 2010 Clutch and flywheel and slave cylinder & pilot bearing and clutch line 8/2/12
Posted ImagePosted ImagePosted Image

#78 OFFLINE   pmustang

pmustang

    Team Shelby New Member

  • Members
  • Pip
  • 238 posts
  • Joined 06-April 10

Posted 10 April 2010 - 02:39 PM

thanks once again for the photos and info.

I have asked the place doing my work how much the pump would be. I would get mighty stung ordering it from the US and shipping it here due to taxes and the broker fees for collecting the taxes. Its hard to determine what will and won't get charged when you ship stuff, I was charged 76 pounds (about 120 US dollars) in taxes and fees just for a sweater my mother sent me! I know, incredible.

thx. Peter

#79 OFFLINE   Mustangmike57

Mustangmike57

    Team Shelby New Member

  • Members
  • Pip
  • 22 posts
  • Joined 12-February 10
  • Interests:Cars, Music, computers, wife and grandchildren

Posted 20 May 2010 - 04:03 AM

Had TSB work done on transmission about 6 weeks go, great results, fixed the problem. Parked the car for 8 days, got in today, dove it about 100 yards to a stop sign, had to let out the clutch in 1st, I felt a little shutter again. It only did it once, maybe a little rust forming on the clutch?
2008 Shelby GT500 White with Blue stripes,Coupe, Shaker 1000, HID Headlamps, Ambient Lighting
Appearance:Pioneer D3, Kicker Rear, Window Tint, JLT Carbon fiber Radiator Cover and extensions, Hood Struts, Strut Tower Covers
Performance: SS Flowmasters JLT CAI, SCT Tune 507 HP, Fly Wheel, Clutch Replaced w 2010 parts
Suspension: Tokico D Spec Dampers, FRPP 1.25 Lowering Kit, MM Mustang Caster Camber Plates, Whiteline Posi-Traction Kit, Upper Panhard Brace, Adjustable Panhard Rod, Rear Swaybar

#80 OFFLINE   jcthorne

jcthorne

    Member Terlingua Racing Team

  • Members
  • PipPip
  • 1,914 posts
  • Joined 10-January 06

Posted 20 May 2010 - 09:16 AM

Are the 2007 thru 2009 Ceramic clutches still available or are the only service parts the 2010 organic clutch?
Gone: GT500 Coupe #3228 Tungsten stripes on Vista Blue

Up next: 2006 Ford GT, Midnight Blue with white stripes.....one day.....

#81 OFFLINE   pmustang

pmustang

    Team Shelby New Member

  • Members
  • Pip
  • 238 posts
  • Joined 06-April 10

Posted 27 May 2010 - 11:30 AM

figured I'd give you guys a report, Since I live in the UK it took quite some time to get the parts, (spec clutch and flywheel and new pump) they tore the car down the other day and the clutch was gone, Reported that normally when clutch is unbolted it pushed off due to the pressure plate exerting pressure on the flywheel, It did not rise off at all (I am only reporting what I remember from the mechanic telling me so I may have it slightly wrong) Said the wear surface of the clutch was all but gone, Said the flywheel was blue. All new spec parts bolted in and hopefully on the road tomorrow. I should have it in my possession in a week or so when me and the seller get together.

Question, does this sound right? sub 5k miles and a clutch that is toast? I know the owner drives 2 miles to and from work so plenty of stop and go. Not that you can tell but he did not appear to be a car abuser and has 2 ferraris if he wants to go even faster.


I just hope the spec clutch and flywheel cure the cause of the problem as the price of repairs here would make your eyes water and I'd like to own the car for a while before spending a huge wodge of cash on it. 9 dollar a gallon petrol is enough pain for me.

cheers. Peter

#82 OFFLINE   Grabber

Grabber

    TS Member #26

  • Moderator
  • 35,148 posts
  • Joined 21-July 06
  • Region:Pacific Northwest

Posted 02 June 2010 - 06:53 PM

figured I'd give you guys a report, Since I live in the UK it took quite some time to get the parts, (spec clutch and flywheel and new pump) they tore the car down the other day and the clutch was gone, Reported that normally when clutch is unbolted it pushed off due to the pressure plate exerting pressure on the flywheel, It did not rise off at all (I am only reporting what I remember from the mechanic telling me so I may have it slightly wrong) Said the wear surface of the clutch was all but gone, Said the flywheel was blue. All new spec parts bolted in and hopefully on the road tomorrow. I should have it in my possession in a week or so when me and the seller get together.

Question, does this sound right? sub 5k miles and a clutch that is toast? I know the owner drives 2 miles to and from work so plenty of stop and go. Not that you can tell but he did not appear to be a car abuser and has 2 ferraris if he wants to go even faster.


I just hope the spec clutch and flywheel cure the cause of the problem as the price of repairs here would make your eyes water and I'd like to own the car for a while before spending a huge wodge of cash on it. 9 dollar a gallon petrol is enough pain for me.

cheers. Peter


Peter,

5K miles could certainly blue the clutch and toast it. The stop and go driving can really heat it up. It also depends on the driver. What you have stated sounds right to me. I hope your problem is cured now.

Edited by Grabber, 02 June 2010 - 06:54 PM.

GRABBER Posted ImagePosted Image
Posted Image 2007 GRABBER ORANGE GT500 Coupe ordered 10/13/06. Sub to plant 12/14/06. Scheduled 1/16/07. Bucked 1/17/07. Released From Plant 1/19/07. Plant Quality Hold 1/19/07. Off Plant Quality Hold 2/21/07. Shipped 2/22/07. Delivered 3/8/07. New 2008 2nd Gen. Tranny & Nickle Hub Clutch & Flywheel & Lube & CSC bearing 1/16/2008. New 2009 2nd Gen. Flywheel & another new Nickel Hub Clutch & Pilot Bearing 8/8/08. New 2010 Clutch and flywheel and slave cylinder & pilot bearing and clutch line 8/2/12
Posted ImagePosted ImagePosted Image

#83 OFFLINE   Deadly Venom

Deadly Venom

    Team Shelby New Member

  • South Atlantic Region
  • 43 posts
  • Joined 23-March 10
  • Region:Decline

Posted 03 June 2010 - 08:30 PM

My clutch went at 3000 miles. I replaced it with a Spec SS billet twin disc clutch and flywheel. It's rated for 900 lbs of torq. My car is hard to put into reverse sometimes it grinds??? Help! What could cause this?
Thanks Bob
'Posted779whp 862wtq...KB 2.8 LCSteeda Triple pass heat exchanger, Meziere 55GPM heat exchanger pump, Extra large factory appearing intercooler coolant tank, Kenne Bell CAI, KB 168mm mono-blade TB, KB super flow intercooler, 3'' upper, Innovators West 10% OD lower, Metco Double Bearing Auxillary Pulley, 10 rib belt, JBA ceramic longtubes, JBA high flow catted X-pipe, & JBA 3" cat-back, 80lb injectors, KB BAP, Black aluminum Fore fuel rails, Shelby Short throw shifter, SPEC SS Twin Disk Carbon Clutch, lightened billet flywheel, Aluminum Dynotech 1 pc driveshaft, BMR Driveshaft loop, TA Billet rearend girdle, Steeda Lower Control Arms, BMR upper 3rd link, Eibach Pro-Kit springs, Koni adj. sport shocks, Eradispeed 2 brake rotos front and rear, Stainless steel braided brake lines, EBC yellow stuff pads front and rear, CS40s wheels, Nitto Invos, 285//30/20 rear, 255/35/20 front, Super Snake triple gauge pod with Shelby signature carbon gauges, Dash Plaque and GT500 sills, Super Snake front carbon splitter, Super Snake carbon rockers, JLT carbon mirror caps, California Special lower scoops, Super Snake upper scoops, sequential tails, "centered" trunklid SHELBY emblem, KR trunk liner & differential catch can. Shelby SS under hood bolt kit. Wrinkle black Shelby coil covers, Shelby/Kicker stereo up grade all speakers/sub and amp. Shelby Redline Hood Quicklift plus gas hood shocks....NX Progressive Maximizer kit (150 wet shot)Evo 93 octane tuneRamsey's nitrous tuneAlways more to come

#84 OFFLINE   treeve

treeve

    Team Shelby Member Since 2007

  • Pacific Coast Region
  • 136 posts
  • Joined 15-November 07
  • Region:Pacific Coast

Posted 05 June 2010 - 02:30 PM

I just wanted to let my fellow Shelby owners know that I just had the TSB completed at Galpin Ford in North Hills (Los Angeles) CA. I did not even purchase my car from there, and there was not one question asked even about about my mods. The took my car in and returned it in four days without a hitch. Way to go Galpin.


Hi, I saw your posting about Galpin Ford doing the TSB warranty work on your Shelby. I have an '07 GT 500 and contacted them about doing the TSB work. Sounds like they took care of you. Anything that I need to know before I take my car in? Thanks.

#85 OFFLINE   pmustang

pmustang

    Team Shelby New Member

  • Members
  • Pip
  • 238 posts
  • Joined 06-April 10

Posted 12 June 2010 - 07:37 AM

Finally got my car the other day, Has a spec stage 3 flywheel and clutch. Car drives quite well, a bit of judder pulling away and sometimes in reverse, other than that everything seems perfect. I have the old clutch and flywheel and will post photos to show you what 5k miles did to the clutch, there is just about nothing left of the wear faces, Amazing!

My skill with the clutch will obviously improve and thus the juddering I am sure will reduce as well.

cheers. Peter

#86 OFFLINE   charleslund

charleslund

    Member for 6 Years

  • Southern Plains Region
  • 40 posts
  • Joined 22-June 08
  • Region:Southern Plains
  • Interests:High Performance Vehicles

Posted 08 July 2010 - 09:22 PM

FINALLY GOT MY '08 BACK AFTER HAVING TO WAIT ON THE CLUTCH ASSEMBLY WITH THE '10 SET UP..THE CLUTCH IS MUCH EASIER AND QUIET. IT WAS WELL WORTH THE TIME IT TOOK FOR ALL THE PARTS TO SHOW UP. HAD THE WORK DONE AT HELFMAN FORD (SW HOUSTON) AND EVERY ONE FROM THE ASSISTANT SERVICE MANAGER, THE SERVICE ADVISOR,THE TECH WHO DID THE WORK AND THE CASHIER MADE THE EXPIERENCE MUCH BETTER THAN I HAD ANTICIPATED..

#87 OFFLINE   Bretts08GT500

Bretts08GT500

    Team Shelby New Member

  • Members
  • Pip
  • 146 posts
  • Joined 07-August 10

Posted 31 August 2010 - 04:37 PM

Wish I could find a Ford dealership that can replace mine. Called all the Ford service departments within 100 miles of Columbia,SC and no one has a tech that has experience with it. Lugoff Ford initialy said the clutch was ok but when I had others look at it they said it was bad. However, they had no one certified to do this clutch. Lugoff told me to bring it back but I don't want to take it to someone that has never done this work before. Any help? Hell, I will drive to North Carolina if someone knows a good dealership that can complete the clutch right.
2008 GT500 convertible

#88 OFFLINE   carrera

carrera

    Team Shelby New Member

  • Members
  • Pip
  • 385 posts
  • Joined 01-December 06

Posted 22 September 2010 - 10:47 AM

What is the difference between flywheel 6375A and flywheel 6375B
2007 GT500, coupe white with blue stripes soon to be a Super Snake #19 at Tasca
Delivered 3/26/07
Birthday 02/07/07
#4987 of 8152 coupes
#1253 of 2252 made in performance white
Converted to Super Snake Oct 9,2008 at Tasca Ford

#89 OFFLINE   DubbsFaris

DubbsFaris

    Southern Plains Bunny Herder

  • Team Shelby Regional Director
  • 4,939 posts
  • Joined 12-November 07
  • Region:Southern Plains
  • Interests:Everything with a snake or a bunny!

Posted 22 September 2010 - 11:01 AM

1 letter. :hysterical:
2008 GT500 Convertible Red Stripe Appearance Package#14 of 131 **SOLD**
2011 GT350 45th Anniversary First GT350 R Tune built and delivered!!! **SOLD**
2014 GT500 Coupe Deep Impact Blue Red Stripes Loaded except Glass roof. 1 of 28 coupes.
2008 Shelby Terlingua Coupe Black with Yellow. 1 of 40-ish. CSCF Raffle car! I won it 3 years late!

TEAM SHELBY SOUTHERN PLAINS REGIONAL DIRECTOR
For Information on regional events and clubs in Arkansas, Louisiana, Oklahoma and Texas, watch the forums!
Other Fords:
2011 SVT Raptor SCrew, Molten Orange
2013 Taurus SHO
2013 Explorer Sport

#90 OFFLINE   carrera

carrera

    Team Shelby New Member

  • Members
  • Pip
  • 385 posts
  • Joined 01-December 06

Posted 22 September 2010 - 11:37 AM

1 letter. :hysterical:


2007 GT500, coupe white with blue stripes soon to be a Super Snake #19 at Tasca
Delivered 3/26/07
Birthday 02/07/07
#4987 of 8152 coupes
#1253 of 2252 made in performance white
Converted to Super Snake Oct 9,2008 at Tasca Ford




0 user(s) are reading this topic

0 members, 0 guests, 0 anonymous users
