need help rear caliper

Started by bigboy , Jun 04 2012 03:48 PM

  • Please log in to reply
14 replies to this topic

#1 OFFLINE   bigboy

bigboy

    Team Shelby New Member

  • Members
  • Pip
  • 12 posts
  • Joined 18-March 08
  • Gender:Male

Posted 04 June 2012 - 03:48 PM

just bought new discs bear and can't get piston of caliper (rear) to go in is there a special tool if so can someone send me pics of tool or any advice would be appreciated

Tks!!!

#2 OFFLINE   ilmor

ilmor

    ilmor

  • Team Shelby Club Member
  • 10,955 posts
  • Joined 04-May 07
  • Gender:Male
  • Region:Northeast
  • Interests:Shelby GT's (what else), Guitar, Camping in my RV, NASCAR, any other auto racing, autocross, car shows
  • Vehicle:Shelby GT

Posted 04 June 2012 - 03:58 PM

You need a tool like this; or a big pair of needle-nose pliers can sometimes be used if its not too tight.

http://carphotos.car...30217_large.jpg
2007 Shelby GT CSM# 07SGT1917 - the "Garage Queen"

Performance White, Hurst 5-Speed, Premium Package



Shelby 4.6L Racing Valve Covers ,Shelby Turbo Mufflers, Shelby GT Brake Duct Kit, "S" snake faux gas cap, Carroll Shelby autographed dash, Improved Shelby GT hood scoop replaced by Tasca Mod Shop, Craig's Custom License Plate Bracket, Baer GT Rotors, Hawk HP Plus Pads, Stainless Steel Brake Lines, Hi Temp Brake Fluid, J&M Street/Race Extreme Joint Lower Control Arms, J&M Double Adjustable Panhard Rod (Street/Race) ...



2013 Mustang GT Premium - the "Daily Driver"

Black / Black & Glass Roof, 6-Speed SelectShift, Sync, NAV, Interior Upgrade.....





Posted Image

#3 OFFLINE   Albino500

Albino500

    Team Shelby Member

  • Team Shelby Club Member
  • 961 posts
  • Joined 19-March 12
  • Gender:Male
  • Region:Pacific Coast
  • Interests:Open track and WOT
  • Vehicle:GT500

Posted 04 June 2012 - 04:13 PM

ilmor is correct with the tool or long needle - nose pliers -BUT remember- you will need to rotate the piston clockwise while pushing in on the piston in order to get it to retract if using the pliers - the tool helps because it only goes one way. Remember to align the (V-shape) holes on the piston to the pin location on the back of the pad or the pad will not seat properly to the piston.

Edited by Albino500, 04 June 2012 - 04:15 PM.

2007 GT500 Built on 7/27/2006
#918 of a build of 8152 coupes
#212 of 2252 in Performance White

Member of Terlingua Racing Team
Member of the "Clean Butt Club" - Class of 2010
2012 Shelby American 50th Anniversary Vegas Bash Car Show "Class" Award Winner

2007 SGT-California Edition Built on 5/15/2007
CSM#07SGT4755
1 of 89 Shelby GT-California Editions done in Performance White/Silver Stripes
Converted to " SCCA SMG Class " race car - 2/04/2013

#4 OFFLINE   bigboy

bigboy

    Team Shelby New Member

  • Members
  • Pip
  • 12 posts
  • Joined 18-March 08
  • Gender:Male

Posted 04 June 2012 - 04:27 PM

View Postilmor, on 04 June 2012 - 03:58 PM, said:

You need a tool like this; or a big pair of needle-nose pliers can sometimes be used if its not too tight.

http://carphotos.car...30217_large.jpg

Tks!!!  for info and pic

#5 OFFLINE   bigboy

bigboy

    Team Shelby New Member

  • Members
  • Pip
  • 12 posts
  • Joined 18-March 08
  • Gender:Male

Posted 04 June 2012 - 04:28 PM

View PostAlbino500, on 04 June 2012 - 04:13 PM, said:

ilmor is correct with the tool or long needle - nose pliers -BUT remember- you will need to rotate the piston clockwise while pushing in on the piston in order to get it to retract if using the pliers - the tool helps because it only goes one way. Remember to align the (V-shape) holes on the piston to the pin location on the back of the pad or the pad will not seat properly to the piston.

Tks!!

#6 OFFLINE   car dude

car dude

    Team Shelby Member

  • Team Shelby Club Member
  • 2,703 posts
  • Joined 18-January 10
  • Gender:Male
  • Interests:Cars,Fishing, Golf,Wife and kids

Posted 05 June 2012 - 04:53 PM

View Postbigboy, on 04 June 2012 - 03:48 PM, said:

just bought new discs bear and can't get piston of caliper (rear) to go in is there a special tool if so can someone send me pics of tool or any advice would be appreciated

Tks!!!
Auto zone will lend for free you that tool that ilmor showed you
[ img]http://Posted Image[/img]

#7 OFFLINE   E.Marquez

E.Marquez

    GearHead

  • Members
  • Pip
  • 165 posts
  • Joined 10-February 12
  • Gender:Male
  • Region:Southern Plains
  • Interests:Motorcycles, off road, on road, track. If it has a motor, and performs well in both left and right turns, I’m interested.
  • Vehicle:GT500

Posted 14 July 2012 - 05:08 AM

If so inclined, it is a pretty simple tool to make as well.
Posted Image
Posted Image
Scrap on hand, 30 sec of cutting, 2 min of grinding, 30 sec of welding.. Less cost in time and gas then it would have cost me to run into town to autozone.
Lateral G-forces make me smile.

#8 OFFLINE   AndyGJ

AndyGJ

    SGT Owner

  • Team Shelby Club Member
  • 824 posts
  • Joined 22-January 08
  • Gender:Male
  • Region:South Atlantic
  • Vehicle:Shelby GT

Posted 14 July 2012 - 06:44 AM

I just bought a set of those tools from Harbor Freight Tools down the street for $39, if that helps any.
The nice aluminum Low Profile Race jack was the expensive part at $150, but I'll use the heck out of it.  The steel one was 105 lbs and this one is 43 lbs.

Andy.
Present Mustang:
2008 Shelby GT Convertible #1676

Mods Installed:
BF Goodrich g-Force Sport COMP-2 Tires (255/45/R18)
CDC Sequential Tail Lights
FRPP GT500KR Axleback Mufflers
FRPP 62mm Throttle Body
FRPP Boss 302 Low Expansion Brakelines
Hawk HPS Brake Pads (front & rear)
JBA Tuned Length Ceramic Shorty Headers
LD's Performance Custom Tuning (91 & 93 Octane) w/SCT-X3 Tuner
Redline Hood Struts (w/update kit)
Royal Purple Synthetic Oil 5w20
Shelby Lower Radiator Grill Insert - Black
Shelby 4.6L Valve Covers
Shelby GT Berg Snake Faux Gas Cap
Shelby GT Berg Snake Front Floor Mats & Trunk Mat
Shelby Plain Rear Seat Floor Mats
Shelby Billet Engine Cap Set Hawk
Shelby Billet Fusebox Cover
Shelby Transmission Cooler Scoop
Shelby Front Brake Duct Cooling Kit
Performance Brake Slotted & Cross Drilled Rotors (front & rear)
Ford Motorcraft DOT4 Brake Fluid
Steeda CAI Intake Elbow w/Black Tubes
Steeda Adjustible Panhard Bar
Steeda Parhard Bar Brace
Steeda Motor Mounts (red inserts)
Steeda Under Drive Pulley

Prior Mustangs:

1968 Mustang Coupe - Midnight Blue
1966 Mustang Convertible 289v2 - Red w/black top & interior (still in the family)
1973 Mustang Convertible 351W - Poppy Red w/black top & interior - MCA Senior Division Grand National Retired Winner
1989 Mustang Hatchback 5.0 w/5spd - 25th Anniversary - Red w/red & black interior

#9 OFFLINE   ///Bruce

///Bruce

    Team Shelby New Member

  • Members
  • Pip
  • 3 posts
  • Joined 26-November 11
  • Gender:Male
  • Region:Other
  • Interests:Cars, chess, cars, reading, cars, cooking, cars....
  • Vehicle:GT500

Posted 18 July 2012 - 08:03 PM

View Postbigboy, on 04 June 2012 - 03:48 PM, said:

just bought new discs bear and can't get piston of caliper (rear) to go in is there a special tool if so can someone send me pics of tool or any advice would be appreciated

Tks!!!

Don't bother with a 'special tool'. Get yourself a big pair of channel pliers. Open those suckers up large enough to grasp the piston and screw it in as far as you need to. Done! Installed rear cross-drilled rotors in 1.2 hours in the rear.

#10 OFFLINE   ///Bruce

///Bruce

    Team Shelby New Member

  • Members
  • Pip
  • 3 posts
  • Joined 26-November 11
  • Gender:Male
  • Region:Other
  • Interests:Cars, chess, cars, reading, cars, cooking, cars....
  • Vehicle:GT500

Posted 18 July 2012 - 08:11 PM

Btw, I didn't read all the other posts but there is a trick: MAKE SURE the slots on the piston are straight up and down. Otherwise you'll never get the caliper back on. There are two nipples on the back of the pads that need to slide down on to install the calper. Learned that the hard way...

#11 OFFLINE   E.Marquez

E.Marquez

    GearHead

  • Members
  • Pip
  • 165 posts
  • Joined 10-February 12
  • Gender:Male
  • Region:Southern Plains
  • Interests:Motorcycles, off road, on road, track. If it has a motor, and performs well in both left and right turns, I’m interested.
  • Vehicle:GT500

Posted 20 July 2012 - 04:25 AM

View Post///Bruce, on 18 July 2012 - 08:11 PM, said:

Btw, I didn't read all the other posts

Really? Never would have guessed :hysterical2:
Lateral G-forces make me smile.

#12 OFFLINE   E.Marquez

E.Marquez

    GearHead

  • Members
  • Pip
  • 165 posts
  • Joined 10-February 12
  • Gender:Male
  • Region:Southern Plains
  • Interests:Motorcycles, off road, on road, track. If it has a motor, and performs well in both left and right turns, I’m interested.
  • Vehicle:GT500

Posted 20 July 2012 - 04:29 AM

View Post///Bruce, on 18 July 2012 - 08:03 PM, said:

Don't bother with a 'special tool'. Get yourself a big pair of channel pliers. Open those suckers up large enough to grasp the piston and screw it in as far as you need to. Done! Installed rear cross-drilled rotors in 1.2 hours in the rear.

To each his own,, but umm channel locks are for plumbing repairs and stuck in the woods, no way to walk out, last ditch chance to get it fixed tools.

If you can afford to buy a GT500, and not the proper tool... or at least one that will not chew up the caliper piston.. perhaps having others work on your car, or buying a car you can afford is a better idea.

NOTE: Channel locks chewing on the caliper piston trying to reset it, is not a great idea... in my opinion.... to each his own, do what works for you.
Lateral G-forces make me smile.

#13 OFFLINE   fcettner

fcettner

    09KR0453

  • Team Shelby Club Member
  • 409 posts
  • Joined 13-October 09
  • Gender:Male
  • Interests:NASCAR Racing (Go Carl Edwards), Fords, Football (Go Steelers) and Baseball (Reds). My Shelby 09KR and other Fords I always seem get my hands on.
  • Vehicle:GT500KR

Posted 20 July 2012 - 11:46 AM

When I do brake work, I use all the proper tooling...just saying.

#14 OFFLINE   6-Speed

6-Speed

    Team Shelby Member

  • Members
  • PipPip
  • 2,471 posts
  • Joined 27-July 07
  • Gender:Male
  • Interests:2007 GT500

Posted 27 July 2012 - 04:39 PM

Even with the correct tool, it took a lot of elbow grease to drive those pistons in.  Wish the end of the tool could accept a 1/2" ratchet.

Posted Image

#15 OFFLINE   zporta

zporta

    Team Shelby Member

  • Members
  • PipPip
  • 529 posts
  • Joined 09-September 08

Posted 05 August 2012 - 12:37 PM

View Post6-Speed, on 27 July 2012 - 04:39 PM, said:

Even with the correct tool, it took a lot of elbow grease to drive those pistons in.  Wish the end of the tool could accept a 1/2" ratchet.

Posted Image

really i have the same tool and it wasnt too bad...
Posted Image
