Clutch fluid line removal - Help


  • Please log in to reply
15 replies to this topic

#1 OFFLINE   RACERX009

RACERX009

    Team Shelby Member

  • Members
  • PipPip
  • 3,546 posts
  • Joined 04-February 08
  • Region:Northeast
  • Interests:2005 BMW M3
    2007 FX35

Posted 06 December 2012 - 01:47 PM

I am at a loss with this dumb line if I had the extra cash then it would be cut. But how the heck did Ford come up with this crap.
Do I drop the transmission and disconnect from slave or from the firewall??? Plus does it unscrew or magically disconnect. Any help would be appreciated!!!
Thanks

Proud borrower of my future wife 2014 Mustang gt Automatic Brenspeed tune and CAI 4.10 gears


#2 OFFLINE   2010KonaBlueGT

2010KonaBlueGT

    There's room at the top. Space is limited...RSVP!

  • Mountain Region
  • 7,264 posts
  • Joined 31-October 09
  • Region:Mountain
  • Interests:Anything Fast - Cars, Motorcycles, Boats, Planes, Women, etc. Building Hi-Po engines. Sailing, Riding Motorcycles (dirt & street), Racing - Motorcycles & Cars, Bowling & Drinking Beer!

Posted 06 December 2012 - 02:05 PM

I am at a loss with this dumb line if I had the extra cash then it would be cut. But how the heck did Ford come up with this crap.
Do I drop the transmission and disconnect from slave or from the firewall??? Plus does it unscrew or magically disconnect. Any help would be appreciated!!!
Thanks


There is a on-line service manual available. I lost the link/bookmark in my HD reload but someone will have it for you.

The process was posted here but that was years ago and I can't remember how. I'd be interested in the answer too as this is something I may end up doing one day.



Phill

2010 GT500 Coupe
Kona Blue w/White OTT Stripes and Red Accent Stripes
Electronics Package, HID's & Car Cover


CURRENT MODS: FRPP: Whipple 2.9L Polished Superchager w/Crusher Inlet & Cobra Jet Dual 65mm Throttle Body - Ceramic Coated Shorty Headers - Ford GT Blue Cam Covers - Polished Billet COP & Oil Filler Cap Covers - FR3 Handling Pack w/Tokico Struts/Shocks & Eibach Swaybars - Jounce Bumpers - 8.8" Low Profile Axle Girdle - 3" Front Brake Cooling Ducts - Vacuum/Boost Gauge~ MGW: Short Throw Shifter - White w/Blue Stripes Shifter Knob - Radiator and Intercooler Degas Bottle Caps - Seat Recliner Lever Covers - Parking Brake Handle Cover - Coat Hanger Hooks~ PST: 1-piece Carbon Fiber Driveshaft~ Revan Racing: C&R Radiator and Intercooler~ ROUSH: 3x Intercooler Degas Bottle - Side Splitters - Extreme Off-road Exhaust - Adjustable Trailing Arms (LCA) - Adjustable 3rd Link (UCA) - Adjustable 3rd Link Bracket - AC Vent Pod Vac/Boost Gauge Mount~ SHELBY: SC Aux. Idler Pulley - Oil Dipstick Handle, MC, PS & WS Washer Reservoir Caps - 8-qt. Oil Pan - Tubular K-Member Subframe - Tubular A-arms - CS S1000 Billet Aluminum Transmission Crossmember - Seat Harness Bar - 6S Extreme Rear Brakes - 6S Extreme Front Brakes - GT500KR Front Brake Cooling Duct Bezels - Anti Bump-stear Tie-rod Ends - Race Style Swaybar Links - Adjustable Caster/Camber Plates - Adjustable Panhard Bar - Panhard Bar/Body Brace - GT500KR Rear Axle Reservoir - Lower Control Arm Relocation Brackets -18" GT500KR Alcoa Dura-Bright Wheels & Goodyear GT500KR Winged Boot F1 Supercar Tires~ Raptor Shift Light

PURCHASED AND AWAITING INSTALLATION: Shelby/Metco Fuel Rails - Shelby Alcoa Forged 20" Dura-Bright Super Snake Style Wheels - Shelby Billet Aluminum Fuel Door - NMB2 2-Stage WOT Box - Granatelli Motors Tire Fryer Line-lock - ZEX N2O kit - Ford Racing Lighted Sill Plates w/Ford Racing logo.



Soon to be "For Sale": Eradispeed Rear Brake Rotors & Caliper Relocation Brackets


#3 OFFLINE   RACERX009

RACERX009

    Team Shelby Member

  • Members
  • PipPip
  • 3,546 posts
  • Joined 04-February 08
  • Region:Northeast
  • Interests:2005 BMW M3
    2007 FX35

Posted 06 December 2012 - 02:36 PM

Thanks I also just bought from lethalperformance a new line its a braided line for 60.00. I have Haynes repair manual and it suxs. I been surfing the Web and nothing once again Ford with a dumb idea.

Proud borrower of my future wife 2014 Mustang gt Automatic Brenspeed tune and CAI 4.10 gears


#4 OFFLINE   2010KonaBlueGT

2010KonaBlueGT

    There's room at the top. Space is limited...RSVP!

  • Mountain Region
  • 7,264 posts
  • Joined 31-October 09
  • Region:Mountain
  • Interests:Anything Fast - Cars, Motorcycles, Boats, Planes, Women, etc. Building Hi-Po engines. Sailing, Riding Motorcycles (dirt & street), Racing - Motorcycles & Cars, Bowling & Drinking Beer!

Posted 06 December 2012 - 04:20 PM

Thanks I also just bought from lethalperformance a new line its a braided line for 60.00. I have Haynes repair manual and it suxs. I been surfing the Web and nothing once again Ford with a dumb idea.


Let me see if I can find it. I have it on my Android but I can't bring up the PDF attachements for some reason.

Here ya go. This is the Root Directory. Click on either the 2005 or the 2011 section for early or later cars.

http://iihs.net/fsm/?dir=0


This one shows the clutch exploded view;
http://iihs.net/fsm/...ve Cylinder.pdf

HTH,
Phill

Edited by 2010KonaBlueGT, 06 December 2012 - 04:27 PM.

2010 GT500 Coupe
Kona Blue w/White OTT Stripes and Red Accent Stripes
Electronics Package, HID's & Car Cover


CURRENT MODS: FRPP: Whipple 2.9L Polished Superchager w/Crusher Inlet & Cobra Jet Dual 65mm Throttle Body - Ceramic Coated Shorty Headers - Ford GT Blue Cam Covers - Polished Billet COP & Oil Filler Cap Covers - FR3 Handling Pack w/Tokico Struts/Shocks & Eibach Swaybars - Jounce Bumpers - 8.8" Low Profile Axle Girdle - 3" Front Brake Cooling Ducts - Vacuum/Boost Gauge~ MGW: Short Throw Shifter - White w/Blue Stripes Shifter Knob - Radiator and Intercooler Degas Bottle Caps - Seat Recliner Lever Covers - Parking Brake Handle Cover - Coat Hanger Hooks~ PST: 1-piece Carbon Fiber Driveshaft~ Revan Racing: C&R Radiator and Intercooler~ ROUSH: 3x Intercooler Degas Bottle - Side Splitters - Extreme Off-road Exhaust - Adjustable Trailing Arms (LCA) - Adjustable 3rd Link (UCA) - Adjustable 3rd Link Bracket - AC Vent Pod Vac/Boost Gauge Mount~ SHELBY: SC Aux. Idler Pulley - Oil Dipstick Handle, MC, PS & WS Washer Reservoir Caps - 8-qt. Oil Pan - Tubular K-Member Subframe - Tubular A-arms - CS S1000 Billet Aluminum Transmission Crossmember - Seat Harness Bar - 6S Extreme Rear Brakes - 6S Extreme Front Brakes - GT500KR Front Brake Cooling Duct Bezels - Anti Bump-stear Tie-rod Ends - Race Style Swaybar Links - Adjustable Caster/Camber Plates - Adjustable Panhard Bar - Panhard Bar/Body Brace - GT500KR Rear Axle Reservoir - Lower Control Arm Relocation Brackets -18" GT500KR Alcoa Dura-Bright Wheels & Goodyear GT500KR Winged Boot F1 Supercar Tires~ Raptor Shift Light

PURCHASED AND AWAITING INSTALLATION: Shelby/Metco Fuel Rails - Shelby Alcoa Forged 20" Dura-Bright Super Snake Style Wheels - Shelby Billet Aluminum Fuel Door - NMB2 2-Stage WOT Box - Granatelli Motors Tire Fryer Line-lock - ZEX N2O kit - Ford Racing Lighted Sill Plates w/Ford Racing logo.



Soon to be "For Sale": Eradispeed Rear Brake Rotors & Caliper Relocation Brackets


#5 OFFLINE   RACERX009

RACERX009

    Team Shelby Member

  • Members
  • PipPip
  • 3,546 posts
  • Joined 04-February 08
  • Region:Northeast
  • Interests:2005 BMW M3
    2007 FX35

Posted 06 December 2012 - 07:12 PM

Thank you!!! I surfed for hours till some topics came up on other Mustang sites. So from what I have read it has a tiny clip holding it together. If you lose the clip your out of luck. But as I said the new flex line should be better and hope it will come with clips. Should be a blast for me with my steady hands. LOL
Thanks again

Proud borrower of my future wife 2014 Mustang gt Automatic Brenspeed tune and CAI 4.10 gears


#6 OFFLINE   TheKurgan

TheKurgan

    Fast Member

  • Southern Plains Region
  • 1,031 posts
  • Joined 09-January 08
  • Region:Mountain
  • Interests:Racing,Flyfishing,Kayaking

Posted 06 December 2012 - 07:38 PM

Be careful that plastic housing is easy to break where it goes into the bellhousing and the small metal cilp will go flying off into neverland. Definitely not one of Ford's better ideas. You have to reuse it. The clutch line is nothing more than a stainless steel line like a brake line.

Edited by TheKurgan, 06 December 2012 - 07:39 PM.

07 SGT - JDM302E, Paxton Novi 1500, Spec 3+, FRPP cams/intake/TB, Kooks, Tial 50mm BOV - 637 rwhp/547 rwtq - Tuned by VMP

Posted Image

#7 OFFLINE   Lgs ShelbyGT

Lgs ShelbyGT

    Team Shelby New Member

  • Pacific Northwest Region
  • 496 posts
  • Joined 19-September 08
  • Region:Pacific Northwest
  • Interests:cars, street bikes, sand dunes & ATVs, snow skiing & martial arts

Posted 06 December 2012 - 11:46 PM

Like TheKrugan said be careful with the clips once you get them out
The clip on the elbow going into the plastic elbow on the bellhousing was easier to remove
Then as careful as we were it disappeared, only to be found months later clear across the shop
FordFan1 fabricated a replacement clip using the handle part of a small spring type paper clip
Ford only sells the assembly - plastic elbow with the clip, yes I bought one, but the custom fab clip is still in service 2 years later
The upper connection was a bit more challenging to get the clip out as there isn't much room to get your hands in there
As I recall it pulls horizontally toward the fender
Best of Luck
Posted ImagePosted Image
2007 Shelby GT Black 07SGT1717
E-force w/FRPP CAI (450 rwhp/443 rwt), McLeod RST, FRPP radiator, Brembos & SS lines, KR r axle reservoir, Steeda LCAs, Roush Off Road axle backs + other stuff
Still setting on the shelf to install: Fays2 Watts Link, FRPP front brake cooling ducts, GT500 splitter, UPR catch can (how to mount it...)
Ancient History:
1965 Mustang - 289 4brl, 4spd, Pony Pack, factory traction bars (1968-1971)
1968 Mustang California Special - 351W 4brl with Shaker hood 426HP
line lock, cool can, Shelby suspension upgrades, etc (1973)

#8 OFFLINE   TheKurgan

TheKurgan

    Fast Member

  • Southern Plains Region
  • 1,031 posts
  • Joined 09-January 08
  • Region:Mountain
  • Interests:Racing,Flyfishing,Kayaking

Posted 07 December 2012 - 04:56 AM

Like TheKrugan said be careful with the clips once you get them out
The clip on the elbow going into the plastic elbow on the bellhousing was easier to remove
Then as careful as we were it disappeared, only to be found months later clear across the shop
FordFan1 fabricated a replacement clip using the handle part of a small spring type paper clip
Ford only sells the assembly - plastic elbow with the clip, yes I bought one, but the custom fab clip is still in service 2 years later
The upper connection was a bit more challenging to get the clip out as there isn't much room to get your hands in there
As I recall it pulls horizontally toward the fender
Best of Luck


That's funny I did the same thng. I found mine about 2 months later. I had the luxury of standing in the engine bay too!
07 SGT - JDM302E, Paxton Novi 1500, Spec 3+, FRPP cams/intake/TB, Kooks, Tial 50mm BOV - 637 rwhp/547 rwtq - Tuned by VMP

Posted Image

#9 OFFLINE   RACERX009

RACERX009

    Team Shelby Member

  • Members
  • PipPip
  • 3,546 posts
  • Joined 04-February 08
  • Region:Northeast
  • Interests:2005 BMW M3
    2007 FX35

Posted 07 December 2012 - 06:34 AM

Thanks guys for all your info !!! I going to cut the plastic line to save me a headache then when reassemblying the line with the new braid one. I will lay a plastic sheet under the master and the clutch lines. If I lose the clip after doing that then its just karma on my end.
What suxs is doing this with limited tools and buying new tools from sears which I hate since my garage at home has double of everything. I have my mom 1 car to do it in and trust me if money wasn't an issue . I would have paid someone to do it but as they say divorce is hell and the poor wife will get her karma out of this. I already folded on my home mortgage cant wait till she has a knock at the door and told to get out. The judge already told her no alimony no maintaince she thought she was going to sit on her butt all day with her new boyfriend. Not

Thanks again

Proud borrower of my future wife 2014 Mustang gt Automatic Brenspeed tune and CAI 4.10 gears


#10 OFFLINE   2007_Shelby_GT

2007_Shelby_GT

    Certified Shelby Nut

  • South Atlantic Region
  • 1,542 posts
  • Joined 18-January 08
  • Region:South Atlantic
  • Interests:Planes, cars, good times, good friends!

Posted 07 December 2012 - 07:49 AM

What are you up to, clutch replacement? You've probably read it elsewhere, but while you're in there, replace the slave cylinder/throwout bearing - consider something better than the stock unit, like the Mcleod adjustable, (with bleeder), expensive, but it will save you heartache later on!

Hang in there!

Sam
AKA:
Posted Image
My Trademark - Don't even think about using it!
In Memory Of Willy T

#11 OFFLINE   TheKurgan

TheKurgan

    Fast Member

  • Southern Plains Region
  • 1,031 posts
  • Joined 09-January 08
  • Region:Mountain
  • Interests:Racing,Flyfishing,Kayaking

Posted 07 December 2012 - 10:20 AM

Yeah that divorce thing sucks. Been there done that. I did the same thing and put all my energy into my car. It's not a bad idea...keeps you from going crazy racer. Don't count on that foreclosure happening soon. Banks are way behind and since the bubble burst, they are scared to call the sheriff and kick people out. They got their hand slapped for doing that by the govt. You can't win against women. Best thing to do is forget about it and hope she will too.
07 SGT - JDM302E, Paxton Novi 1500, Spec 3+, FRPP cams/intake/TB, Kooks, Tial 50mm BOV - 637 rwhp/547 rwtq - Tuned by VMP

Posted Image

#12 OFFLINE   RACERX009

RACERX009

    Team Shelby Member

  • Members
  • PipPip
  • 3,546 posts
  • Joined 04-February 08
  • Region:Northeast
  • Interests:2005 BMW M3
    2007 FX35

Posted 07 December 2012 - 03:06 PM

Thanks bud and trust me I can't afford this clutch job. The shifting go so bad it was killing my shoulder and hand. I use to drive the stang when loopy from the drugs and probably damaged it. So driving upstate in traffic was a nitemares. I tried hitting my mom up for the install money but she said no to that. I do have my f100 but I have an order of protection Against me so I can't get it. My cousin won't go and get it for me he doesn't want to get involved. So it sits their and awaits me saving her and it would help me out too drive that around. But my hands are tied and far as that but the mortgage company has this deal. I sign my home over to them and no foreclosure on my credit report.

Proud borrower of my future wife 2014 Mustang gt Automatic Brenspeed tune and CAI 4.10 gears


#13 OFFLINE   RACERX009

RACERX009

    Team Shelby Member

  • Members
  • PipPip
  • 3,546 posts
  • Joined 04-February 08
  • Region:Northeast
  • Interests:2005 BMW M3
    2007 FX35

Posted 07 December 2012 - 03:07 PM

Thanks bud and trust me I can't afford this clutch job. The shifting go so bad it was killing my shoulder and hand. I use to drive the stang when loopy from the drugs and probably damaged it. So driving upstate in traffic was a nitemares. I tried hitting my mom up for the install money but she said no to that. I do have my f100 but I have an order of protection Against me so I can't get it. My cousin won't go and get it for me he doesn't want to get involved. So it sits their and awaits me saving her and it would help me out too drive that around. But my hands are tied and far as that but the mortgage company has this deal. I sign my home over to them and no foreclosure on my credit report.

Proud borrower of my future wife 2014 Mustang gt Automatic Brenspeed tune and CAI 4.10 gears


#14 OFFLINE   RACERX009

RACERX009

    Team Shelby Member

  • Members
  • PipPip
  • 3,546 posts
  • Joined 04-February 08
  • Region:Northeast
  • Interests:2005 BMW M3
    2007 FX35

Posted 13 December 2012 - 09:49 AM

If you remove the evaporation canister you can access the line and swap it in 10 minutes. Also I have read the night mare of just changing out the line. You have to lower transmission to get at line. But what if you make an access panel from inside the car. You can make a flap in the rug then cut a 4 in by 4in in the tunnel use sheet metal screws with a 5 in square to cover.
Just a thought

Proud borrower of my future wife 2014 Mustang gt Automatic Brenspeed tune and CAI 4.10 gears


#15 OFFLINE   Lgs ShelbyGT

Lgs ShelbyGT

    Team Shelby New Member

  • Pacific Northwest Region
  • 496 posts
  • Joined 19-September 08
  • Region:Pacific Northwest
  • Interests:cars, street bikes, sand dunes & ATVs, snow skiing & martial arts

Posted 13 December 2012 - 10:53 PM

If you remove the evaporation canister you can access the line and swap it in 10 minutes.


Interesting idea
The canister definitely made access to the upper clip difficult, but we eventually got it done
Posted ImagePosted Image
2007 Shelby GT Black 07SGT1717
E-force w/FRPP CAI (450 rwhp/443 rwt), McLeod RST, FRPP radiator, Brembos & SS lines, KR r axle reservoir, Steeda LCAs, Roush Off Road axle backs + other stuff
Still setting on the shelf to install: Fays2 Watts Link, FRPP front brake cooling ducts, GT500 splitter, UPR catch can (how to mount it...)
Ancient History:
1965 Mustang - 289 4brl, 4spd, Pony Pack, factory traction bars (1968-1971)
1968 Mustang California Special - 351W 4brl with Shaker hood 426HP
line lock, cool can, Shelby suspension upgrades, etc (1973)

#16 OFFLINE   RACERX009

RACERX009

    Team Shelby Member

  • Members
  • PipPip
  • 3,546 posts
  • Joined 04-February 08
  • Region:Northeast
  • Interests:2005 BMW M3
    2007 FX35

Posted 14 December 2012 - 07:58 AM

Interesting idea
The canister definitely made access to the upper clip difficult, but we eventually got it done

Trust me next time transmission comes out I will design a better setup than what is in place now. Especially as access is a nightmare !!!
