Wideband A/F Ratio Recommendations


  • Please log in to reply
4 replies to this topic

#1 OFFLINE   Radical08

Radical08

    Team Shelby New Member

  • Members
  • Pip
  • 393 posts
  • Joined 19-December 07
  • Region:South Atlantic
  • Interests:Fast cars

Posted 16 December 2012 - 10:07 AM

A few questions here on the wideband topic;

-The 2011 and up Mustangs and Shelby have wideband O2 sensors installed already correct, and the 2010 does not?

-I want a dual wideband, any recommendations on which one? I have only seen 2 out there that are dual

#2 OFFLINE   2010KonaBlueGT

2010KonaBlueGT

    There's room at the top. Space is limited...RSVP!

  • Members
  • PipPipPip
  • 7,321 posts
  • Joined 31-October 09
  • Region:Mountain
  • Interests:Anything Fast - Cars, Motorcycles, Boats, Planes, Women, etc. Building Hi-Po engines. Sailing, Riding Motorcycles (dirt & street), Racing - Motorcycles & Cars, Bowling & Drinking Beer!

Posted 16 December 2012 - 11:18 AM

-The 2011 and up Mustangs and Shelby have wideband O2 sensors installed already correct, and the 2010 does not?
-I want a dual wideband, any recommendations on which one? I have only seen 2 out there that are dual


I know for sure the 2010 has a HEGO (4-wire) sensor and not a UEGO (5-wire, aka 'wideband') sensor.

I can't remember which was the first year but it was either 2011 or 2012. I'm pretty sure it was the '11 because that's when they went to a frequency based MAF Sensor so the PCM would be different and more probably used a UEGO vs. HEGO sensor.

I'm curious though...Why do you desire a dual sensor system?


Phill

2010 GT500 Coupe
Kona Blue w/White OTT Stripes and Red Accent Stripes
Electronics Package, HID's & Car Cover


CURRENT MODS: FRPP: Whipple 2.9L Polished Superchager w/Crusher Inlet & Cobra Jet Dual 65mm Throttle Body - Ceramic Coated Shorty Headers - Ford GT Blue Cam Covers - Polished Billet COP & Oil Filler Cap Covers - FR3 Handling Pack w/Tokico Struts/Shocks & Eibach Swaybars - Jounce Bumpers - 8.8" Low Profile Axle Girdle - 3" Front Brake Cooling Ducts - Vacuum/Boost Gauge~ MGW: Short Throw Shifter - White w/Blue Stripes Shifter Knob - Radiator and Intercooler Degas Bottle Caps - Seat Recliner Lever Covers - Parking Brake Handle Cover - Coat Hanger Hooks~ PST: 1-piece Carbon Fiber Driveshaft~ Revan Racing: C&R Radiator and Intercooler~ ROUSH: 3x Intercooler Degas Bottle - Side Splitters - Extreme Off-road Exhaust - Adjustable Trailing Arms (LCA) - Adjustable 3rd Link (UCA) - Adjustable 3rd Link Bracket - AC Vent Pod Vac/Boost Gauge Mount~ SHELBY: SC Aux. Idler Pulley - Oil Dipstick Handle, MC, PS & WS Washer Reservoir Caps - 8-qt. Oil Pan - Tubular K-Member Subframe - Tubular A-arms - CS S1000 Billet Aluminum Transmission Crossmember - Seat Harness Bar - 6S Extreme Rear Brakes - 6S Extreme Front Brakes - GT500KR Front Brake Cooling Duct Bezels - Anti Bump-stear Tie-rod Ends - Race Style Swaybar Links - Adjustable Caster/Camber Plates - Adjustable Panhard Bar - Panhard Bar/Body Brace - GT500KR Rear Axle Reservoir - Lower Control Arm Relocation Brackets -18" GT500KR Alcoa Dura-Bright Wheels & Goodyear GT500KR Winged Boot F1 Supercar Tires~ Raptor Shift Light

PURCHASED AND AWAITING INSTALLATION: Shelby/Metco Fuel Rails - Shelby Alcoa Forged 20" Dura-Bright Super Snake Style Wheels - Shelby Billet Aluminum Fuel Door - NMB2 2-Stage WOT Box - Granatelli Motors Tire Fryer Line-lock - ZEX N2O kit - Ford Racing Lighted Sill Plates w/Ford Racing logo.



Soon to be "For Sale": Eradispeed Rear Brake Rotors & Caliper Relocation Brackets


#3 OFFLINE   Radical08

Radical08

    Team Shelby New Member

  • Members
  • Pip
  • 393 posts
  • Joined 19-December 07
  • Region:South Atlantic
  • Interests:Fast cars

Posted 16 December 2012 - 12:51 PM

I was thinking it would be best to monitor both sides being a V8 but maybe really not needed just one side. Too bad the 10 did not have the wideband because that would have been simple to do. I guess most just do one side monitoring

#4 OFFLINE   AZ08GT500

AZ08GT500

    Team Shelby New Member

  • Members
  • Pip
  • 24 posts
  • Joined 06-July 12
  • Region:Mountain
  • Interests:I love cars and street racing, I have a 2013 GT500.

Posted 16 December 2012 - 08:17 PM

Fast sells a duel wide bad system, buts its really not necessary. I run mine off the driver side. AEM or innovate sell very nice ones.

19c16c86-3985-4b0d-8acd-54786521b055_zps
2013 GT500, VMP Tuned, VMP 67MM T/B, JLT 127MM intake, 2.39 pulley, kooks axle back and some 315 DRs


#5 OFFLINE   Radical08

Radical08

    Team Shelby New Member

  • Members
  • Pip
  • 393 posts
  • Joined 19-December 07
  • Region:South Atlantic
  • Interests:Fast cars

Posted 21 December 2012 - 03:55 AM

Ok here is the deal on the 2010 GT500. I have a AEM Wideband installed now and not so hard really. On the driver side thereis room in that short section of pipe between the converter and the manifold at the 1 o clock position for a sensor. The wire goes right up and there is a firewall opening right by the brake cable it fits through. Get the Roush vent pod for the gage, connect ground and switched power and wala done and a wideband in the car without buying a $450 H-Pipe or something else or doing it half ass so to speak. Works out well on the driver side because nothing is there. You can't do it on the passenger side and I'm only using one like most do anyway. So $175 from Summit or Jegs and a very good AEM wideband that does not require all the calibrations that most do.
